How half cell modules work:
If an entire solar cell is cut into two half pieces, one half piece produce half as much current and one fourth resistance of the whole piece. Thus, the quantity of cells will be double. If they are wired up to work like a full cell panel, the current will be the same but with half the resistance. The electrical losses would be less due to the lower resistance.
Cells connection type
But if the half cut cells were wired together as in a standard full cell panel, they would produce twice the voltage and half the current. To make the output like standard full cell panels, the type of the half cells connection is different. There are two lots of half quantity series-connected cells. These two lots are connected in parallel. Voltages in parallel stay the same and the half cell panel remains the same voltage as the full cell panel.
