Experience the future of construction with Jiaqiang's Expandable Container Houses. From quick assembly to unmatched durability and sustainability, our solutions redefine modern living.
Product Description
Jiaqiang container house is a welded structure with galvanized steel structure, which can be prefabbed in the factory and assembled on site;
Jiaqiang box house has a seismic resistance of 8 levels and a wind resistance of 10 levels;
Living in Jiaqiang Expandable container house, you will feel bright, breathable. The wall is well soundproof, and has a good heat insulation effect;
There is no construction waste during the installation process;
It can be stacked up to 3 floors and there is no limitation to add the rooms up transversely;
It is easy to install, easy to disassemble and there will be no construction waste left while installation or disasssembly;
The construction cycle is shortened by 80% compared to traditional buildings, the construction labor is saved by 70%, the coagulation loss is reduced by 98%, the construction water is reduced by 70%, and the comprehensive energy saving exceeds 50%;
Jiaqiang box house is movable and reusable. The room unit structure is a standard component welded with special shaped steel, and the boxes are connected by bolts.
Jiaqiang Extended Container House Default Design | ||||
1 | External Dimensions | Length | 5900mm (19'4'') | |
2 | Width | 6300mm (20'8'') | ||
3 | Height | 2480mm (8'2'') | ||
4 | Indoor Dimensions | Length | 5640mm (18'6'') | |
5 | Width | 6140mm (20'2'') | ||
6 | Height | 2240mm (7'4'') | ||
7 | Stack | Maximum Layers | ≤3 layers | |
8 | Horizontal Expansion | Unlimited | ||
9 | Main Frame | Steel Column | galvanized coil extruded steel (SGH340), 448mm*150mm*210mm, t=2.5mm | |
10 | Roof Main Beams | galvanized coil extruded steel (SGH340), 465mm*180mm, t=2.5mm | ||
11 | Roof Secondary Beams | galvanized strip extruded steel (Q235B), C175mm, t=1.5mm | ||
12 | Bottom Main Beams | galvanized coil extruded steel (SGH340), 415mm*160mm, t=2.5mm | ||
13 | Ground Sub-beam | galvanized strip extruded steel (Q235B), C206mm, t=1.5mm | ||
14 | Surface Rreatment | electrostatic powder coating | ||
15 | Roof | Roof Panel | galvanized color-coated roll, 360Degree of bite, white gray, t=0.4mm | |
16 | Thermal Insulation | glass wool, flame retardant A-class, test weight ≥14kg/m³, t=75mm | ||
17 | Ceiling Panel | galvanized color-coated roll-forming, 193 sealed shadowless ceiling, white gray, t=0.4mm | ||
18 | Ground | Decorative Surface | white and gray multi-layer composite PVC floor, flame retardant B₁-class, t=1.6mm | |
19 | Substrate+Waterproof Film | cement board, density ≥1.2g/m³, flame retardant A-class, t=18mm | ||
20 | Wall | Color Coated Plate | 1150S, double-sided 0.32mm, with orange peel texture on the outside and flat inside, Jinghua galvanized aluminum color-coated plate | |
21 | Thermal Insulation | flame retardant glass wool, test weight ≥55kg/m³, flame retardant A-class, t=50mm | ||
22 | Door | Specification | W925mm*H1970mm | |
23 | Material | steel door | ||
24 | Window | Specification | W1120mm*H1100mm, equipped with screens and security bars | |
25 | Material | ordinary sliding window with insulation transparent glass | ||
26 | Electricity | Voltage | 220V~250V, 50Hz, 3rd class, 32A | |
27 | Wire | main power cord=6mm², air conditioning line=4mm², socket cord=2.5mm², lighting switch wire=1.5mm² | ||
28 | Power supply | aviation industry plug, 220V, 3 cores, 32A | ||
29 | Breaker | high breaking miniature circuit breaker, equipped with leakage switch | ||
30 | Lighting | 36W LED fluorescent lamp, 2 sets | ||
31 | Switches & Sockets | 1 set of 10A single switch, 2 sets of 10A five-hole socket, 1 set of 16A three-hole Delixi air conditioning socket | ||
32 | Water | Water Supply | Φ25 PPR tube | |
33 | Drainage | Φ50 UPVC tube*2/Φ110 UPVC tube*2 | ||
34 | Decorate | Package | galvalume color coated coil bending parts, t=0.5, color: Jinghua White | |
35 | Structural Glue | neutral silicone weather-resistant glue (good elasticity, fast curing, high strength, good corrosion resistance) | ||
36 | Others | MOQ | 6 sets | |
Port | Tianjin Port or customer specified | |||
Supply Capability | 6000 sets/month | |||
Payment | 100% payment before shipping by T/T |
