Biogas System Equipments

Biogas System Equipment is mainly used to make gas pressure meet the standards, maintain stable pressure, and the continuity of supply. It’s characteristic is safety, easy to transport and easy for installation, stable gas pressure, automatic control equipment.

The pressurized and regulated pressure supply system designed and produced by our company is mainly used for methane pressurization, pressure regulation and gas supply. The tank body and pipeline of this system are generally carbon steel anticorrosion, and the pressurized fan, electric control cabinet and controller are explosion-proof, which can be safely used in every area of biogas project. After setting the pressure value of the system, the booster fan will automatically start or stop according to the methane pressure in the buffer tank to ensure the stability of pressure in the tank. The system can be customized according to the customer's requirements in terms of external dimensions, fan and buffer tank models. Methane inlet and outlet pipe height and pipe diameter can also be adjusted to meet the needs of each project.

Positive and negative pressure protector

Specifications according to the actual situation custom, the material is divided into carbon steel and enamel.

Description of positive and negative pressure protector

By tanks, tank bottom, air inlet pipe, pressure pipe, and unloading, including tanks can be separated by pipeline according to certain volume ratio, injection water after appropriate, when gas pressure is greater than standard atmospheric pressure is greater than 4 kpa or than normal atmospheric pressure is less than 0.5 kpa, emptying the intake mouth, thereby identifying protection function, the protector has simple structure, reliable, convenient installation. At the same time, the material is carbon steel or 304 stainless steel plate, with good anticorrosion performance, durable. The above advantages make this product has a high cost performance.
